API Reference

Story(data=None, width=None, height=None, font=None, base_font_size=None, template=None, geodata=False, geojson_url=None, geojson_property=None, geo_property=None, geo_value=None, **kwargs)

Story class: Implements a structure for creating narrative views of data.

This class extends the functionality of Altair to include narrative elements
such as titles, contexts, and call-to-action elements. It is designed to facilitate
the creation of more engaging and informative data visualisations.

Parameters:

Name	Type	Description	Default
data	DataFrame | str	DataFrame or URL/path containing the chart data. Defaults to None.	None
width	int	Graph width in pixels. If omitted or None, uses the preferred width from the template (if used), falling back to 600. Defaults to None.	None
height	int	Graph height in pixels. If omitted or None, uses the preferred height from the template (if used), falling back to 400. Defaults to None.	None
font	str	Font family to be applied to all text elements. If omitted or None, uses the value from the template (if used), falling back to Times New Roman for the title (if used) and Noto Sans for all the rest. Defaults to None.	None
base_font_size	int | float	Base font size in pixels. If omitted or None, uses the value from the template (if used) Defaults to None.	None
template	Template | type[Template]	Instance or subclass of Template for styling. If omitted or None, uses DefaultTemplate(). Defaults to None.	None
geodata	bool	Indicates whether the chart handles spatial data. Defaults to False.	False
geojson_url	str, optional, required if `geodata=True`	File path or URL to the GeoJSON file. Required if geodata=True. Defaults to None.	None
geojson_property	str, optional, required if `geodata=True`	Key property name in the GeoJSON used for merging. Required if geodata=True. Defaults to None.	None
geo_property	str, optional, required if `geodata=True`	DataFrame column name matching geojson_property. Required if geodata=True. Defaults to None.	None
geo_value	str, optional, required if `geodata=True`	DataFrame column name containing the numerical or categorical values to map spatially. Required if geodata=True. Defaults to None.	None
**kwargs		Additional keyword arguments passed directly to the alt.Chart constructor.	{}

Raises:

Type	Description
ValueError	If template is neither an instance nor a subclass of Template.
ValueError	If geodata=True and any required spatial arguments (geojson_url, geojson_property, geo_property, geo_value) are missing.
ValueError	If geojson_url does not have a .json or .geojson extension.
ValueError	If geo_property or geo_value are not valid columns in data.

Source code in pynarrative/src/pynarrative/story.py

def __init__(
        self,
        data=None,
        width=None,
        height=None,
        font=None,
        base_font_size=None,
        template=None,
        geodata = False,
        geojson_url = None,
        geojson_property = None,
        geo_property = None,
        geo_value = None,
        **kwargs
    ):

    """Story class: Implements a structure for creating narrative views of data.

        This class extends the functionality of Altair to include narrative elements
        such as titles, contexts, and call-to-action elements. It is designed to facilitate
        the creation of more engaging and informative data visualisations.


    Args:
        data (pandas.DataFrame | str, optional): DataFrame or URL/path containing
            the chart data. Defaults to None.
        width (int, optional): Graph width in pixels. If omitted or None, uses the
            preferred width from the template (if used), falling back to 600. Defaults to None.
        height (int, optional): Graph height in pixels. If omitted or None, uses the
            preferred height from the template (if used), falling back to 400. Defaults to None.
        font (str, optional): Font family to be applied to all text elements.
            If omitted or None, uses the value from the template (if used), falling back to
            Times New Roman for the title (if used) and Noto Sans for all the rest.
            Defaults to None.
        base_font_size (int | float, optional): Base font size in pixels.
            If omitted or None, uses the value from the template (if used)
            Defaults to None.
        template (Template | type[Template], optional): Instance or subclass of
            `Template` for styling. If omitted or None, uses `DefaultTemplate()`.
            Defaults to None.
        geodata (bool, optional): Indicates whether the chart handles spatial data.
            Defaults to False.
        geojson_url (str, optional, required if `geodata=True`): File path or URL to the GeoJSON file.
            Required if `geodata=True`. Defaults to None.
        geojson_property (str, optional, required if `geodata=True`): Key property name in the GeoJSON used for
            merging. Required if `geodata=True`. Defaults to None.
        geo_property (str, optional, required if `geodata=True`): DataFrame column name matching `geojson_property`.
            Required if `geodata=True`. Defaults to None.
        geo_value (str, optional, required if `geodata=True`): DataFrame column name containing the numerical or
            categorical values to map spatially. Required if `geodata=True`.
            Defaults to None.
        **kwargs: Additional keyword arguments passed directly to the `alt.Chart`
            constructor.

    Raises:
        ValueError: If `template` is neither an instance nor a subclass of `Template`.
        ValueError: If `geodata=True` and any required spatial arguments
            (`geojson_url`, `geojson_property`, `geo_property`, `geo_value`) are missing.
        ValueError: If `geojson_url` does not have a `.json` or `.geojson` extension.
        ValueError: If `geo_property` or `geo_value` are not valid columns in `data`.
    """
    if template is None:
        template = DefaultTemplate()
    elif isinstance(template, type) and issubclass(template, Template):
        template = template()
    elif not isinstance(template, Template):
        raise ValueError("template must be a Template instance or Template subclass")

    if font is not None:
        template.style.set_font(font)
    if base_font_size is not None:
        template.style.set_base_font_size(base_font_size)

    #Managing geographical data
    if geodata and None in [geojson_url, geojson_property, geo_property, geo_value]:
        raise ValueError("if `geodata=True`, 'geojson_url', 'geojson_property', 'geo_property', 'geo_value' are required arguments")
    if geodata:
        if geojson_url: #Checking extension
            if os.path.splitext(geojson_url)[1] not in [".geojson", ".json"]:
                raise ValueError("'geojson_url' must be a .geojson or .json file")
        if geo_property not in data.columns:
            raise ValueError(f"'{geo_property}' must be a column in your dataframe")
        if geo_value not in data.columns:
                raise ValueError(f"'{geo_value}' must be a column in your dataframe")

    if geodata:
        geo_dataframe = gpd.read_file(geojson_url)
        geo_dataframe = geo_dataframe.merge(data, left_on = geojson_property, right_on = geo_property, how = "left")
        geo_dataframe[geo_value] = geo_dataframe[geo_value].fillna(0)
        data = geo_dataframe


    self.template = template
    self.font = template.font
    self.base_font_size = template.base_font_size
    chart_width = width if width is not None else self.chart_style_value(template, 'preferred_width', 600)
    self.chart_width = chart_width

    chart_height = height if height is not None else self.chart_style_value(template, 'preferred_height', 400)

    # Initialising the Altair Chart object with basic parameters
    self.chart = alt.Chart(data, width=chart_width, height=chart_height, **kwargs)
    self.story_layers = []  # List for storing history layers

    # Dictionaries for the sizes and colours of various text elements
    # These values are multipliers for base_font_size
    self.style = template.style
    self.layout = template.layout
    self.font_sizes = self.style['font_sizes']
    self.colors = self.style['colors']
    self.context_box = self.style['context_box']
    self.chart_style = {**self.style, **self.layout}
    self.config = {}
    self._warned_about_manual_override = False

add_labels_chart(values=None, color=None, orientation='horizontal', angle=0, dx=0, dy=0, font_size=11, font_weight='normal', geodata=False, geodata_label=None)

Adds custom text labels to an existing chart layer or map visualization.

Creates an Altair mark_text layer positioned relative to existing chart encodings or geodata centroids. Supports custom orientations, offsets, and fonts.

Parameters:

Name	Type	Description	Default
values	str | list | Series	Column name or explicit list of values to display as labels. If None, automatically defaults to the Y-axis encoding field. Defaults to None.	None
color	str	Custom fill color for the label text. If omitted or None, falls back to the chart_label_color defined in the template style settings. Defaults to None.	None
orientation	str	Preset label layout orientation. Must be one of 'horizontal', 'vertical_left' (angle=90), or 'vertical_right' (angle=270). For custom rotations, use 'horizontal' and set angle directly. Defaults to "horizontal".	'horizontal'
angle	int | float	Label rotation angle in degrees. Must be between 0 and 360. Cannot be combined with preset orientations other than 'horizontal'. Defaults to 0.	0
dx	int | float	Horizontal pixel offset for text positioning. Defaults to 0.	0
dy	int | float	Vertical pixel offset for text positioning. Defaults to 0.	0
font_size	int | float	Font size of the text labels in pixels. Defaults to 11.	11
font_weight	str	Font weight for the label text. Must be one of 'normal' or 'bold'. Defaults to "normal".	'normal'
geodata	bool	Whether the target chart represents geographic map data. If True, labels are placed on spatial geometry centroids. Defaults to False.	False
geodata_label	str	The column name containing text labels when geodata=True. Required if geodata is True. Defaults to None.	None

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If numerical parameters (angle, dx, dy, font_size) receive boolean or non-numeric types.
TypeError	If geodata is not a boolean.
ValueError	If used on multi-series charts without enabling geodata=True.
ValueError	If angle is not between 0 and 360 degrees.
ValueError	If orientation is not one of 'horizontal', 'vertical_left', or 'vertical_right'.
ValueError	If a non-zero angle is combined with 'vertical_left' or 'vertical_right'.
ValueError	If font_weight is not 'normal' or 'bold'.
ValueError	If geodata=True but geodata_label is omitted.
ValueError	If no Y-axis encoding or explicit values can be resolved.

Source code in pynarrative/src/pynarrative/story.py

def add_labels_chart(self,
                     values = None,
                     color = None,
                     orientation = "horizontal",
                     angle=0,
                     dx=0,
                     dy=0,
                     font_size=11,
                     font_weight="normal",
                     geodata = False,
                     geodata_label = None
                     ):
    """Adds custom text labels to an existing chart layer or map visualization.

    Creates an Altair `mark_text` layer positioned relative to existing chart encodings
    or geodata centroids. Supports custom orientations, offsets, and fonts.

    Args:
        values (str | list | pandas.Series, optional): Column name or explicit list of values
            to display as labels. If None, automatically defaults to the Y-axis encoding field.
            Defaults to None.
        color (str, optional): Custom fill color for the label text. If omitted or None,
            falls back to the `chart_label_color` defined in the template style settings.
            Defaults to None.
        orientation (str, optional): Preset label layout orientation. Must be one of
            `'horizontal'`, `'vertical_left'` (angle=90), or `'vertical_right'` (angle=270).
            For custom rotations, use `'horizontal'` and set `angle` directly.
            Defaults to "horizontal".
        angle (int | float, optional): Label rotation angle in degrees. Must be between 0 and 360.
            Cannot be combined with preset orientations other than `'horizontal'`.
            Defaults to 0.
        dx (int | float, optional): Horizontal pixel offset for text positioning.
            Defaults to 0.
        dy (int | float, optional): Vertical pixel offset for text positioning.
            Defaults to 0.
        font_size (int | float, optional): Font size of the text labels in pixels.
            Defaults to 11.
        font_weight (str, optional): Font weight for the label text. Must be one of
            `'normal'` or `'bold'`. Defaults to "normal".
        geodata (bool, optional): Whether the target chart represents geographic map data.
            If True, labels are placed on spatial geometry centroids. Defaults to False.
        geodata_label (str, optional): The column name containing text labels when `geodata=True`.
            Required if `geodata` is True. Defaults to None.

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If numerical parameters (`angle`, `dx`, `dy`, `font_size`) receive boolean or non-numeric types.
        TypeError: If `geodata` is not a boolean.
        ValueError: If used on multi-series charts without enabling `geodata=True`.
        ValueError: If `angle` is not between 0 and 360 degrees.
        ValueError: If `orientation` is not one of `'horizontal'`, `'vertical_left'`, or `'vertical_right'`.
        ValueError: If a non-zero `angle` is combined with `'vertical_left'` or `'vertical_right'`.
        ValueError: If `font_weight` is not `'normal'` or `'bold'`.
        ValueError: If `geodata=True` but `geodata_label` is omitted.
        ValueError: If no Y-axis encoding or explicit `values` can be resolved.
    """

    if not isinstance(geodata, bool):
        raise TypeError(f"'geodata' must be a boolean, got {type(geodata).__name__}")

    if isinstance(angle, bool) or not isinstance(angle, (int, float)):
        raise TypeError(f"'angle' must be a numeric integer or float, got {type(angle).__name__}")

    if not (0 <= angle <= 360):
        raise ValueError(f"Value of 'angle' must be between 0 and 360, got {angle}")

    if isinstance(dx, bool) or not isinstance(dx, (int, float)):
        raise TypeError(f"'dx' must be a numeric integer or float, got {type(dx).__name__}")

    if isinstance(dy, bool) or not isinstance(dy, (int, float)):
        raise TypeError(f"'dy' must be a numeric integer or float, got {type(dy).__name__}")

    if isinstance(font_size, bool) or not isinstance(font_size, (int, float)) or font_size <= 0:
        raise TypeError(f"'font_size' must be a positive number, got {type(font_size).__name__}")

    if font_weight not in ["normal", "bold"]:
        raise ValueError(f"Invalid 'font_weight' value: '{font_weight}'. Must be 'normal' or 'bold'")

    has_series, _ = self._get_encoding_field_and_type("color")
    if has_series is not None and not geodata:
        raise ValueError(
            "add_labels_chart cannot be used on charts with multiple series. "
            "For geographical data, set 'geodata = True'."
        )


    preset_orientations = ["horizontal", "vertical_left", "vertical_right"]
    if orientation not in preset_orientations:
        raise ValueError(
            f"Invalid 'orientation' value: '{orientation}'. Must be one of {preset_orientations}. "
            "For custom layouts, use 'horizontal' with explicit angle, dx, and dy settings."
        )

    if orientation != "horizontal" and angle != 0:
        raise ValueError(
            f"Cannot specify a custom angle ({angle}) when using orientation '{orientation}'. "
            "Use orientation 'horizontal' when specifying custom angles."
        )

    if orientation == "vertical_left":
        angle = 90
    if orientation == "vertical_right":
        angle = 270


    mark_color = color if color else self.colors.get("chart_label_color", "#000000")

    if geodata:
        if geodata_label is None:
            raise ValueError("When 'geodata=True', you must specify 'geodata_label'.")
        elif ":" not in geodata_label:
            raise ValueError("You must specify the geodata_label value encoding (ex: 'value:Q' for quantities or 'word:N' for nominal values).")
        else:
            label = geodata_label.split(":")[0]
            label_encoding = geodata_label.split(":")[1]

            values = self.data.copy()
            centroids = values.geometry.to_crs(epsg=3035).centroid.to_crs(epsg=4326)
            values["lon"] = centroids.x
            values["lat"] = centroids.y
            self.label_layer = alt.Chart(values[values[label].notna()]).mark_text(
                align = "center",
                dx = dx,
                dy = dy,
                lineBreak="\n",
                angle = angle,
                color = mark_color,
                fontSize = font_size,
                fontWeight = font_weight
            ).encode(
                longitude = "lon:Q",
                latitude = "lat:Q",
                text=f"{label}:{label_encoding}",
            )

            return self


    y_enc = self.encoding.get("y") if isinstance(self.encoding, dict) else getattr(self.encoding, "y", None)

    if y_enc is not None:
        shorthand = getattr(y_enc, "shorthand", str(y_enc))
        field_name = shorthand.split(":")[0] if ":" in shorthand else shorthand
        labels = f"{field_name}:Q"
    else:
        labels = None

    if values is not None and len(values) > 0:
        if not isinstance(values, (str, list, pd.Series)):
            raise TypeError("'values' must be a column name (str), a list, or a pandas Series.")

        if isinstance(values, str):
            if ":" in values:
                labels = values
            else:
                if values in self.data.columns and pd.api.types.is_numeric_dtype(self.data[values]):
                    labels = f"{values}:Q"
                else:
                    labels = f"{values}:N"

        elif isinstance(values, (list, pd.Series)):
            first_elem = values[0] if isinstance(values, list) else values.iloc[0]
            data_type = "Q" if isinstance(first_elem, (int, float, np.number)) else "N"

            chart_data = self.data.copy()
            chart_data["_custom_label"] = values
            self.data = chart_data
            labels = f"_custom_label:{data_type}"

    if not labels:
        raise ValueError(
            "Could not resolve labels: ensure self.encoding['y'] is set "
            "or provide a valid 'values' parameter."
        )

    text_encoding = alt.Text(labels)

    self.label_layer = alt.Chart(self.data).encode(
        x=self.encoding['x'],
        y=self.encoding['y'],
        text=text_encoding
    ).mark_text(
        align = "center",
        dx = dx,
        dy = dy,
        lineBreak="\n",
        angle = angle,
        color = mark_color,
        fontSize = font_size,
        fontWeight = font_weight
        )

    return self

add_title(title, subtitle=None, background_color=None, color=None, align='center', img_url=None, img_width=80, x_img_offset=-300, y_img_offset=0)

Adds a main title layer and an optional subtitle to the story.

Parameters:

Name	Type	Description	Default
title	str	Main title text to display.	required
subtitle	str	Subtitle text to display below the title. Defaults to None.	None
background_color	str	Background color for the title block. If omitted or None, falls back to the title_background_color defined in the template. Defaults to None.	None
color	str	Text color for the title and subtitle. If omitted or None, falls back to the title defined in the template. Defaults to None.	None
align	str	Horizontal text alignment. Must be one of 'left', 'center', or 'right'. Defaults to "center".	'center'
img_url	str	URL or path to an optional image/logo to display alongside the title. Defaults to None.	None
img_width	int | float	Width of the image in pixels. Defaults to 80.	80
x_img_offset	int | float	Horizontal offset for the image position relative to the title block in pixels. Defaults to -300.	-300
y_img_offset	int | float	Vertical offset for the image position relative to the title block in pixels. Defaults to 0.	0

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If title is not a string.
ValueError	If align is not one of 'left', 'center', or 'right'.
ValueError	If img_width is less than or equal to 0 when img_url is provided.

Source code in pynarrative/src/pynarrative/story.py

def add_title(
        self,
        title,
        subtitle=None,
        background_color = None,
        color = None,
        align = "center",

        img_url = None,
        img_width = 80,
        x_img_offset = -300,
        y_img_offset = 0

        ):
    """Adds a main title layer and an optional subtitle to the story.

    Args:
        title (str): Main title text to display.
        subtitle (str, optional): Subtitle text to display below the title.
            Defaults to None.
        background_color (str, optional): Background color for the title block.
            If omitted or None, falls back to the `title_background_color` defined
            in the template. Defaults to None.
        color (str, optional): Text color for the title and subtitle.
            If omitted or None, falls back to the `title` defined
            in the template. Defaults to None.
        align (str, optional): Horizontal text alignment. Must be one of
            `'left'`, `'center'`, or `'right'`. Defaults to "center".
        img_url (str, optional): URL or path to an optional image/logo to display
            alongside the title. Defaults to None.
        img_width (int | float, optional): Width of the image in pixels.
            Defaults to 80.
        x_img_offset (int | float, optional): Horizontal offset for the image position
            relative to the title block in pixels. Defaults to -300.
        y_img_offset (int | float, optional): Vertical offset for the image position
            relative to the title block in pixels. Defaults to 0.

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `title` is not a string.
        ValueError: If `align` is not one of `'left'`, `'center'`, or `'right'`.
        ValueError: If `img_width` is less than or equal to 0 when `img_url` is provided.
    """

    #GESTIONE ERRORI
    if align not in ["left", "center", "right"]:
        raise ValueError(f"Invalid 'align' value: '{align}'. Must be one of: 'left', 'center', 'right'")

    if img_url is not None and img_width <= 0:
        raise ValueError("'img_width' must be a positive number")

    background_color = background_color if background_color else self.colors["title_background_color"]
    color = color if color else self.colors["title"]

    self.story_layers.append({
        'type': 'title',
        'title': title,
        'subtitle': subtitle,
        "align": align,
        "color": color,
        "background_color": background_color,
        "img_url": img_url,
        "img_width": img_width,
        "x_img_offset": x_img_offset,
        "y_img_offset": y_img_offset
    })
    return self

add_context(text, text_align='left', position='left', align='middle', width_multiplier=None, height_multiplier=None, font_weight='normal', font_style='normal', title='CONTEXT', title_dy=0, img_url=None, img_width=60, x_img_offset=-40, y_img_offset=0)

Adds a context box layer to the story.

Parameters:

Name	Type	Description	Default
text	str	The body text to be displayed within the context box.	required
text_align	str	Horizontal alignment of the text inside the box. Must be one of 'left', 'center', or 'right'. Defaults to "left".	'left'
position	str	Position of the context box relative to the chart. Must be one of 'left', 'right', 'top', or 'bottom'. Defaults to "left".	'left'
align	str	Vertical alignment relative to the chart when position is 'left' or 'right'. Must be one of 'top', 'middle', or 'bottom'. Defaults to "middle".	'middle'
width_multiplier	(int, float)	Box width multiplier (suggested values: from 0.1 to 4). If omitted or None, uses the value from the template (if used), falling back to the standard value (1.7)	None
height_multiplier	(int, float)	Box height multiplier (suggested values: from 0.1 to 0.75). If omitted or None, uses the value from the template (if used), falling back to the standard value (0.33)	None
font_weight	str	Font weight for the context text. Must be one of 'normal' or 'bold'. Defaults to "normal".	'normal'
font_style	str	Font style for the context text. Must be one of 'normal' or 'italic'. Defaults to "normal".	'normal'
title	str	Title header displayed above the context text. Defaults to "CONTEXT".	'CONTEXT'
title_dy	int | float	Vertical offset in pixels for the title relative to its default position. Defaults to 0.	0
img_url	str	File path or URL to an image/icon displayed alongside the context block. Defaults to None.	None
img_width	int | float	Width of the context image in pixels. Defaults to 60.	60
x_img_offset	int | float	Horizontal offset in pixels for the context image. Defaults to -40.	-40
y_img_offset	int | float	Vertical offset in pixels for the context image. Defaults to 0.	0

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If text or title is not a string.
TypeError	If width_multiplier is not int or float.
TypeError	If height_multiplier is not int or float.
ValueError	If text_align is not one of 'left', 'center', or 'right'.
ValueError	If position is not one of 'left', 'right', 'top', or 'bottom'.
ValueError	If align is specified with position set to 'top' or 'bottom'.
ValueError	If align is not one of 'top', 'middle', or 'bottom'.
ValueError	If font_weight is not one of 'normal' or 'bold'.
ValueError	If font_style is not one of 'normal' or 'italic'.
ValueError	If img_width is less than or equal to 0 when img_url is provided.

Source code in pynarrative/src/pynarrative/story.py

def add_context(
        self,
        text,
        text_align = "left",
        position='left',
        align = "middle",
        width_multiplier = None,
        height_multiplier = None,
        font_weight = "normal",
        font_style = "normal",
        title = "CONTEXT",
        title_dy = 0,
        img_url = None,
        img_width = 60,
        x_img_offset = -40,
        y_img_offset = 0
    ):
    """Adds a context box layer to the story.

    Args:
        text (str): The body text to be displayed within the context box.
        text_align (str, optional): Horizontal alignment of the text inside the box.
            Must be one of `'left'`, `'center'`, or `'right'`. Defaults to "left".
        position (str, optional): Position of the context box relative to the chart.
            Must be one of `'left'`, `'right'`, `'top'`, or `'bottom'`. Defaults to "left".
        align (str, optional): Vertical alignment relative to the chart when `position` is
            `'left'` or `'right'`. Must be one of `'top'`, `'middle'`, or `'bottom'`.
            Defaults to "middle".
        width_multiplier (int, float, optional): Box width multiplier (suggested values: from 0.1 to 4).
            If omitted or None, uses the value from the template (if used),
            falling back to the standard value (1.7)
        height_multiplier (int, float, optional): Box height multiplier (suggested values: from 0.1 to 0.75).
            If omitted or None, uses the value from the template (if used),
            falling back to the standard value (0.33)
        font_weight (str, optional): Font weight for the context text.
            Must be one of `'normal'` or `'bold'`. Defaults to "normal".
        font_style (str, optional): Font style for the context text.
            Must be one of `'normal'` or `'italic'`. Defaults to "normal".
        title (str, optional): Title header displayed above the context text.
            Defaults to "CONTEXT".
        title_dy (int | float, optional): Vertical offset in pixels for the title relative
            to its default position. Defaults to 0.
        img_url (str, optional): File path or URL to an image/icon displayed alongside
            the context block. Defaults to None.
        img_width (int | float, optional): Width of the context image in pixels.
            Defaults to 60.
        x_img_offset (int | float, optional): Horizontal offset in pixels for the context image.
            Defaults to -40.
        y_img_offset (int | float, optional): Vertical offset in pixels for the context image.
            Defaults to 0.

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `text` or `title` is not a string.
        TypeError: If `width_multiplier` is not int or float.
        TypeError: If `height_multiplier` is not int or float.
        ValueError: If `text_align` is not one of `'left'`, `'center'`, or `'right'`.
        ValueError: If `position` is not one of `'left'`, `'right'`, `'top'`, or `'bottom'`.
        ValueError: If `align` is specified with `position` set to `'top'` or `'bottom'`.
        ValueError: If `align` is not one of `'top'`, `'middle'`, or `'bottom'`.
        ValueError: If `font_weight` is not one of `'normal'` or `'bold'`.
        ValueError: If `font_style` is not one of `'normal'` or `'italic'`.
        ValueError: If `img_width` is less than or equal to 0 when `img_url` is provided.
    """

    #GESTIONE ERRORI

    if not isinstance(text, str):
        raise TypeError(f"'text' must be a string, got {type(text).__name__}")
    if title is not None and not isinstance(title, str):
        raise TypeError(f"'title' must be a string, got {type(title).__name__}")
    if text_align not in ["left", "center", "right"]:
        raise ValueError(f"Invalid 'text_align' value: '{text_align}'. Must be one of: 'left', 'center', 'right'")
    if position not in ['bottom', 'top', 'left', 'right']:
        raise ValueError(f"Invalid 'position' value: '{position}'. Must be one of: 'bottom', 'top', 'left', 'right'")
    if position in ["top", "bottom"] and align != "middle":
        raise ValueError("Vertical alignment ('align') cannot be customized when 'position' is 'top' or 'bottom'")
    if align not in ["top", "middle", "bottom"]:
        raise ValueError(f"Invalid 'align' value: '{align}'. Must be one of: 'top', 'middle', 'bottom'")
    if not isinstance(width_multiplier, (int, float)) and width_multiplier is not None:
        raise TypeError(f"'width_multiplier' must be int or float, got {type(width_multiplier).__name__}")
    if not isinstance(height_multiplier, (int, float)) and height_multiplier is not None:
        raise TypeError(f"'height_multiplier' must be int or float, got {type(height_multiplier).__name__}")
    if font_weight not in ["normal", "bold"]:
        raise ValueError(f"Invalid 'font_weight' value: '{font_weight}'. Must be one of: 'normal', 'bold'")
    if font_style not in ["normal", "italic"]:
        raise ValueError(f"Invalid 'font_style' value: '{font_style}'. Must be one of: 'normal', 'italic'")
    if img_url is not None and img_width <= 0:
        raise ValueError("'img_width' must be a positive number")

    font_size_px = self.em_to_px(self.font_sizes['context'])

    self._calculate_width_multipliers(text, position, block_type_ = "context", width_multiplier = width_multiplier, height_multiplier = height_multiplier)

    box_width, box_height = self._context_box_size(position)
    wrapped_text = self._wrap_text_for_width(
        text,
        box_width=box_width,
        font_size_px=font_size_px,
    )

    self.story_layers.append({
        'type': 'context',
        'text': wrapped_text,
        "text_align" : text_align,
        'position': position,
        'box_width': box_width,
        'box_height': box_height,
        "align" : align,
        "font_weight" : font_weight,
        "font_style" : font_style,
        "title" : title,
        "title_dy" : title_dy,
        "img_url": img_url,
        "img_width": img_width,
        "x_img_offset": x_img_offset,
        "y_img_offset": y_img_offset
    })

    return self

add_next_steps(steps, text_align='left', position='bottom', width_multiplier=None, height_multiplier=1, title='NEXT STEPS', title_dy=0, title_dx=0, mode='horizontal', img_url=None, img_width=45, x_img_offset=-50, y_img_offset=-22.5)

Adds next steps as a row or column of styled boxes with a shared title.

Parameters:

Name	Type	Description	Default
steps	list[str] | str	Sequence of step descriptions to display. A single string will be automatically converted into a one-element list.	required
text_align	str	Horizontal alignment of the text inside each step box. Must be one of 'left', 'center', or 'right'. Defaults to "left".	'left'
position	str	Position of the entire element relative to the chart. Must be one of 'bottom', 'top', 'left', or 'right'. Defaults to "bottom".	'bottom'
width_multiplier	(int, float)	Box width multiplier (suggested values: from 0.1 to 4). If omitted or None, uses the value from the template (if used), falling back to the standard value (1.7)	None
height_multiplier	(int, float)	Box height multiplier (suggested values: from 0.1 to 4). If omitted or None, uses the value from the template (if used), falling back to the standard value	1
title	str	Main title header displayed above the next steps. Defaults to "NEXT STEPS".	'NEXT STEPS'
title_dy	int | float	Vertical offset in pixels for the title. If omitted or 0, falls back to the nextstep_title_offset defined in the template. Defaults to 0.	0
title_dx	int | float	Horizontal offset in pixels for the title. Defaults to 0.	0
mode	str	Layout orientation for displaying the step boxes. Must be either 'horizontal' or 'vertical'. Defaults to "horizontal".	'horizontal'
img_url	str | list[str]	URL/path or list of URLs/paths for icons associated with each step. If a list is provided, its length must match steps. Defaults to None.	None
img_width	int | float	Width and height of the step icons in pixels. Defaults to 45.	45
x_img_offset	int | float	Horizontal offset in pixels for icon positioning. Defaults to -50.	-50
y_img_offset	int | float	Vertical offset in pixels for icon positioning. Defaults to -22.5.	-22.5

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If steps is not a string or a list of strings.
TypeError	If img_url is provided but is neither a string nor a list.
TypeError	If width_multiplier is not int or float.
TypeError	If height_multiplier is not int or float.
ValueError	If steps is empty or contains more than 5 elements.
ValueError	If position is not one of 'bottom', 'top', 'left', or 'right'.
ValueError	If text_align is not one of 'left', 'center', or 'right'.
ValueError	If mode is not 'horizontal' or 'vertical'.
ValueError	If img_url as a list does not match the length of steps.
ValueError	If img_width is less than or equal to 0 when img_url is provided.

Source code in pynarrative/src/pynarrative/story.py

def add_next_steps(
    self,
    steps,
    text_align = "left",
    position='bottom',
    width_multiplier = None,
    height_multiplier = 1,
    title="NEXT STEPS",
    title_dy = 0,
    title_dx = 0,
    mode = "horizontal",
    img_url = None,
    img_width = 45,
    x_img_offset = -50,
    y_img_offset = -22.5
):

    """Adds next steps as a row or column of styled boxes with a shared title.

    Args:
        steps (list[str] | str): Sequence of step descriptions to display.
            A single string will be automatically converted into a one-element list.
        text_align (str, optional): Horizontal alignment of the text inside each step box.
            Must be one of `'left'`, `'center'`, or `'right'`. Defaults to "left".
        position (str, optional): Position of the entire element relative to the chart.
            Must be one of `'bottom'`, `'top'`, `'left'`, or `'right'`. Defaults to "bottom".
        width_multiplier (int, float, optional): Box width multiplier (suggested values: from 0.1 to 4).
            If omitted or None, uses the value from the template (if used),
            falling back to the standard value (1.7)
        height_multiplier (int, float, optional): Box height multiplier (suggested values: from 0.1 to 4).
            If omitted or None, uses the value from the template (if used),
            falling back to the standard value
        title (str, optional): Main title header displayed above the next steps.
            Defaults to "NEXT STEPS".
        title_dy (int | float, optional): Vertical offset in pixels for the title.
            If omitted or 0, falls back to the `nextstep_title_offset` defined in the template.
            Defaults to 0.
        title_dx (int | float, optional): Horizontal offset in pixels for the title.
            Defaults to 0.
        mode (str, optional): Layout orientation for displaying the step boxes.
            Must be either `'horizontal'` or `'vertical'`. Defaults to "horizontal".
        img_url (str | list[str], optional): URL/path or list of URLs/paths for icons
            associated with each step. If a list is provided, its length must match `steps`.
            Defaults to None.
        img_width (int | float, optional): Width and height of the step icons in pixels.
            Defaults to 45.
        x_img_offset (int | float, optional): Horizontal offset in pixels for icon positioning.
            Defaults to -50.
        y_img_offset (int | float, optional): Vertical offset in pixels for icon positioning.
            Defaults to -22.5.

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `steps` is not a string or a list of strings.
        TypeError: If `img_url` is provided but is neither a string nor a list.
        TypeError: If `width_multiplier` is not int or float.
        TypeError: If `height_multiplier` is not int or float.
        ValueError: If `steps` is empty or contains more than 5 elements.
        ValueError: If `position` is not one of `'bottom'`, `'top'`, `'left'`, or `'right'`.
        ValueError: If `text_align` is not one of `'left'`, `'center'`, or `'right'`.
        ValueError: If `mode` is not `'horizontal'` or `'vertical'`.
        ValueError: If `img_url` as a list does not match the length of `steps`.
        ValueError: If `img_width` is less than or equal to 0 when `img_url` is provided.
    """
    if steps is None:
        raise ValueError("The parameter 'steps' is required")
    if isinstance(steps, str):
        steps = [steps]
    if not isinstance(steps, list) or not all(isinstance(s, str) for s in steps):
        raise TypeError("'steps' must be a string or a list of strings")
    if len(steps) < 1:
        raise ValueError("Must provide at least one step")
    if len(steps) > 5:
        raise ValueError("Maximum number of steps is 5")
    if position not in ["bottom", "top", "left", "right"]:
        raise ValueError(f"Invalid 'position' value: '{position}'. Must be one of: 'bottom', 'top', 'left', 'right'")
    if not isinstance(width_multiplier, (int, float)) and width_multiplier is not None:
        raise TypeError(f"'width_multiplier' must be int or float, got {type(width_multiplier).__name__}")
    if not isinstance(height_multiplier, (int, float)) and height_multiplier is not None:
        raise TypeError(f"'height_multiplier' must be int or float, got {type(height_multiplier).__name__}")
    if text_align not in ["left", "center", "right"]:
        raise ValueError(f"Invalid 'text_align' value: '{text_align}'. Must be one of: 'left', 'center', 'right'")
    if mode not in ["horizontal", "vertical"]:
        raise ValueError(f"Invalid 'mode' value: '{mode}'. Must be one of: 'horizontal', 'vertical'")

    if img_url is not None:
        if not isinstance(img_url, (list, str)):
            raise TypeError("'img_url' must be a list or a string")
        elif len(img_url) != len(steps):
                raise ValueError(f"Length of 'img_url' list ({len(img_url)}) must match length of 'steps' ({len(steps)})")

    if img_width <= 0:
        raise ValueError("'img_width' must be a positive number")

    self._calculate_width_multipliers(steps, position, block_type_ = f"nextsteps_{mode}", width_multiplier = width_multiplier, height_multiplier = None)

    font_family = self.font
    font_size = self.em_to_px(self.font_sizes["nextstep"])
    title_color = self.colors['nextstep_title']

    gap = self.chart_style['nextstep_gap']
    text_top_padding_px = self.chart_style.get('nextstep_text_top_padding_px', max(4, font_size * 0.35))
    text_bottom_padding_px = self.chart_style.get('nextstep_text_bottom_padding_px', text_top_padding_px)
    text_side_padding_px = self.chart_style.get('nextstep_text_side_padding_px', max(6, font_size * 0.4))
    line_gap_px = self.chart_style.get('nextstep_line_gap_px', max(1.0, font_size * 0.15))
    line_height_px = font_size + line_gap_px
    layout_width = self._layout_width()
    min_box = self.chart_style['nextstep_min_box_width']
    max_box = self.chart_style['nextstep_max_box_width']

    # NUOVO
    if mode == "horizontal":
        box_width, _ = self._context_box_size(position) #Il calcolo della larghezza utilizza lo stesso metodo del box di contesto per questioni di uniformità grafica
        content_width = (box_width * len(steps)) + (gap * (len(steps) - 1))
        chart_width = max(layout_width, content_width)
    else: #vertical
        box_width, _ = self._context_box_size(position) #Il calcolo della larghezza utilizza lo stesso metodo del box di contesto per questioni di uniformità grafica
        chart_width = box_width

    box_color = self.colors['nextstep_box']
    box_border = self.colors['nextstep_border']
    text_color = self.colors['nextstep_text']


    wrapped_steps = []
    box_heights = []
    for step in steps:
        wrapped = self._wrap_text_for_width( #uniformazione alla gestione dei box di contesto
            str(step),
            box_width = box_width,
            font_size_px = font_size,
        )
        wrapped_steps.append(wrapped)
        box_heights.append(self._text_block_height(wrapped, font_size, block_type = "nextsteps"))  #uniformazione alla gestione dei box di contesto


    uniform_box_height = (max(box_heights) * height_multiplier) if box_heights else self.chart_style['nextstep_box_height']
    chart_body_height = uniform_box_height


    rows = []

    text_align = text_align if text_align is not None else self.chart_style['nextstep_text_align']
    if mode == "horizontal":
        for i, step_text in enumerate(wrapped_steps):
            x_left = i * (box_width + gap)
            if text_align == "left":
                x_mid = x_left +  (box_width / 10)
            elif text_align == "center":
                x_mid = x_left +  (box_width / 2)
            else: #right
                x_mid = x_left + box_width - 10
            rows.append({
                'x': x_left,
                'y': 0,
                'x2': x_left + box_width,
                'y2': uniform_box_height,
                'text': step_text,
                'x_mid': x_mid,
                'y_text': uniform_box_height - text_top_padding_px,
        })
    else: #vertical
        total_body_height = sum(box_heights) + (gap * (len(steps) - 1))
        chart_body_height = total_body_height

        current_top = total_body_height
        for i, step_text in enumerate(wrapped_steps):
            h_i = box_heights[i]
            y_bottom = current_top - h_i
            if text_align == "left":
                x_mid = text_side_padding_px
            elif text_align == "center":
                x_mid = box_width / 2
            else: #right
                x_mid = box_width - text_side_padding_px
            rows.append({
                'x': 0,
                'y': y_bottom,
                'x2': box_width,
                'y2': current_top,
                'text': step_text,
                'x_mid': x_mid,
                'y_text': current_top - text_top_padding_px,
            })
            current_top = y_bottom - gap

    df_rect = pd.DataFrame(rows)

    rect = alt.Chart(df_rect).mark_rect(
        color=box_color,
        opacity=self.chart_style['nextstep_opacity'],
        cornerRadius=self.chart_style['nextstep_corner_radius'],
        stroke=box_border,
        strokeWidth=self.chart_style['nextstep_border_width']
    ).encode(
        x=alt.X('x:Q', axis=None),
        y=alt.Y('y:Q', axis=None),
        x2='x2:Q',
        y2='y2:Q'
    ).properties(
        width = chart_width,
        height = chart_body_height + self.chart_style['nextstep_chart_height_padding']
    )

    text = alt.Chart(df_rect).mark_text(
        color = text_color,
        font = font_family,
        fontSize = font_size,
        align = text_align,
        baseline = "top",
        lineBreak = self.chart_style['text_line_break'],
        lineHeight = font_size * self.chart_style['context_line_height_ratio'], #uniformazione alla gestione dei box di contesto
    ).encode(
        text = "text:N",
        x = alt.X('x_mid:Q', axis=None),
        y = alt.Y('y_text:Q', axis=None),
    )

    if img_url:
        df_rect["img_url"] = img_url
        img_layer = alt.Chart(df_rect).mark_image(
            width = img_width,
            height = img_width,
            baseline = "bottom",
            xOffset = x_img_offset,
            yOffset = y_img_offset
        ).encode(
            x = alt.X('x:Q', axis=None),
            y = alt.Y('y:Q', axis=None),
            url = "img_url:N",
        )
        chart = alt.layer(rect, text, img_layer)
    else:
        chart = alt.layer(rect, text)

    title_dy = title_dy if title_dy else self.chart_style["nextstep_title_offset"]
    if title:
        dx = title_dx
        if img_url:
            dx = x_img_offset + title_dx
        chart = chart.properties(
            title=alt.TitleParams(
                text = [title],
                fontSize = self.em_to_px(self.font_sizes["nextstep"]) + 5,
                font = font_family,
                color = title_color,
                fontWeight = "bold",
                align = "center",
                baseline = "top",
                dx = dx,
                offset = title_dy,
            )
        )

    self.story_layers.append({
        'type': 'special_cta',
        'chart': chart,
        'position': position
    })

    return self

add_source(text, position='top', vertical=False, align='center')

Adds a source (or credits) attribution layer to the story.

Parameters:

Name	Type	Description	Default
text	str	The source text or attribution to display.	required
position	str	Position of the source relative to the chart. Must be one of 'top', 'bottom', 'left', or 'right'. Defaults to "top".	'top'
vertical	bool	Whether to rotate the text 90 degrees. Defaults to False.	False
align	str	Horizontal text alignment when position is 'top' or 'bottom'. Must be one of 'left', 'center', or 'right'. Defaults to "center".	'center'

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If text is not a string.
TypeError	If vertical is not a boolean.
ValueError	If position is not one of 'top', 'bottom', 'left', or 'right'.
ValueError	If align is specified (other than default 'center') when position is 'left' or 'right'.
ValueError	If align is not one of 'left', 'center', or 'right'.

Source code in pynarrative/src/pynarrative/story.py

def add_source(self, text, position='top', vertical=False, align = "center"):
    """Adds a source (or credits) attribution layer to the story.

    Args:
        text (str): The source text or attribution to display.
        position (str, optional): Position of the source relative to the chart.
            Must be one of `'top'`, `'bottom'`, `'left'`, or `'right'`.
            Defaults to "top".
        vertical (bool, optional): Whether to rotate the text 90 degrees.
            Defaults to False.
        align (str, optional): Horizontal text alignment when `position` is `'top'` or
            `'bottom'`. Must be one of `'left'`, `'center'`, or `'right'`.
            Defaults to "center".

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `text` is not a string.
        TypeError: If `vertical` is not a boolean.
        ValueError: If `position` is not one of `'top'`, `'bottom'`, `'left'`, or `'right'`.
        ValueError: If `align` is specified (other than default `'center'`) when `position`
            is `'left'` or `'right'`.
        ValueError: If `align` is not one of `'left'`, `'center'`, or `'right'`.
    """

    #GESTIONE ERRORI
    if not isinstance(text, str):
        raise TypeError(f"'text' must be a string, got {type(text).__name__}")
    if not isinstance(vertical, bool):
        raise TypeError(f"'vertical' must be a boolean, got {type(vertical).__name__}")
    if position not in ['bottom', 'top', 'left', 'right']:
        raise ValueError(f"Invalid 'position' value: '{position}'. Must be one of: 'top', 'bottom', 'left', 'right'")
    if position in ["left", "right"] and align != "center":
        raise ValueError("Horizontal alignment ('align') cannot be customized when 'position' is 'left' or 'right'")
    if align not in ["left", "center", "right"]:
        raise ValueError(f"Invalid 'align' value: '{align}'. Must be one of: 'left', 'center', 'right'")

    self.story_layers.append({
        'type': 'source',
        'text': text,
        'position': position,
        'vertical': vertical,
        "align": align
    })

    return self

add_annotation(x=None, y=None, text=None, title=None, dx=0, dy=0, background_color=None, text_color=None, show_subject=False, line_point_color=None, img_url=None, img_width=60, x_img_offset=0, y_img_offset=0)

Adds an annotation layer anchored to quantitative (x, y) coordinates.

Parameters:

Name	Type	Description	Default
x	int | float	Subject X-coordinate in chart data space.	None
y	int | float	Subject Y-coordinate in chart data space.	None
text	str	Main annotation body text. Required if img_url is None. Defaults to None.	None
title	str	Title header prepended above the text. Defaults to None.	None
dx	int | float	Horizontal pixel offset from the subject point to the annotation box corner. Defaults to 0.	0
dy	int | float	Vertical pixel offset from the subject point to the annotation box corner. Defaults to 0.	0
background_color	str	Background color for the annotation box. If omitted or None, falls back to the annotation_fill defined in the template or the context box fill setting. Defaults to None.	None
text_color	str	Text color for the annotation label. If omitted or None, falls back to the annotation_text defined in the template or context color settings. Defaults to None.	None
show_subject	bool	If True, draws a point marker at (x, y) and a connecting line to the annotation box, that slightly shifts. Defaults to False.	False
line_point_color	str	Custom color for the connecting line and subject point marker. If omitted or None, falls back to text_color. Defaults to None.	None
img_url	str	URL or file path for an image/icon inside the annotation. Required if text is None. Defaults to None.	None
img_width	int | float	Width and height of the annotation image in pixels. Defaults to 60.	60
x_img_offset	int | float	Horizontal pixel offset for the image position. Defaults to 0.	0
y_img_offset	int | float	Vertical pixel offset for the image position. Defaults to 0.	0
**kwargs		Unused keyword arguments.	required

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If show_subject is not a boolean.
ValueError	If both x and y are not provided, or are non-numeric.
ValueError	If both text and img_url are missing.
ValueError	If either the X or Y chart axes are not quantitative ('Q').
ValueError	If axis numeric ranges cannot be resolved.
ValueError	If img_width is less than or equal to 0 when img_url is provided.

Source code in pynarrative/src/pynarrative/story.py

def add_annotation(
    self,
    x=None,
    y=None,
    text=None,
    title=None,
    dx=0,
    dy=0,
    background_color = None,
    text_color = None,
    show_subject = False,
    line_point_color = None,
    img_url = None,
    img_width = 60,
    x_img_offset = 0,
    y_img_offset = 0,
):
    """Adds an annotation layer anchored to quantitative (x, y) coordinates.

    Args:
        x (int | float): Subject X-coordinate in chart data space.
        y (int | float): Subject Y-coordinate in chart data space.
        text (str, optional): Main annotation body text. Required if `img_url` is None.
            Defaults to None.
        title (str, optional): Title header prepended above the text. Defaults to None.
        dx (int | float, optional): Horizontal pixel offset from the subject point
            to the annotation box corner. Defaults to 0.
        dy (int | float, optional): Vertical pixel offset from the subject point
            to the annotation box corner. Defaults to 0.
        background_color (str, optional): Background color for the annotation box.
            If omitted or None, falls back to the `annotation_fill` defined in the
            template or the context box fill setting. Defaults to None.
        text_color (str, optional): Text color for the annotation label.
            If omitted or None, falls back to the `annotation_text` defined in the
            template or context color settings. Defaults to None.
        show_subject (bool, optional): If True, draws a point marker at (x, y) and
            a connecting line to the annotation box, that slightly shifts. Defaults to False.
        line_point_color (str, optional): Custom color for the connecting line and
            subject point marker. If omitted or None, falls back to `text_color`.
            Defaults to None.
        img_url (str, optional): URL or file path for an image/icon inside the annotation.
            Required if `text` is None. Defaults to None.
        img_width (int | float, optional): Width and height of the annotation image in pixels.
            Defaults to 60.
        x_img_offset (int | float, optional): Horizontal pixel offset for the image position.
            Defaults to 0.
        y_img_offset (int | float, optional): Vertical pixel offset for the image position.
            Defaults to 0.
        **kwargs: Unused keyword arguments.

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `show_subject` is not a boolean.
        ValueError: If both `x` and `y` are not provided, or are non-numeric.
        ValueError: If both `text` and `img_url` are missing.
        ValueError: If either the X or Y chart axes are not quantitative ('Q').
        ValueError: If axis numeric ranges cannot be resolved.
        ValueError: If `img_width` is less than or equal to 0 when `img_url` is provided.
    """

    if x is None or y is None:
        raise ValueError("add_annotation requires x and y coordinates.")
    if text is None and img_url is None:
        raise ValueError("add_annotation requires at least 'text' or 'img_url'.")
    if not isinstance(show_subject, bool):
        raise TypeError(f"'show_subject' must be a boolean, got {type(show_subject).__name__}")

    x_field, x_type = self._get_encoding_field_and_type('x')
    y_field, y_type = self._get_encoding_field_and_type('y')
    if x_type != 'Q' or y_type != 'Q':
        raise ValueError("add_annotation supports only quantitative ('Q') x/y axes.")

    try:
        x = float(x)
        y = float(y)
    except (TypeError, ValueError):
        raise ValueError("add_annotation requires numeric x and y values.")

    x_min, x_max = self._get_axis_range(x_field)
    y_min, y_max = self._get_axis_range(y_field)
    if x_min is None or x_max is None or y_min is None or y_max is None:
        raise ValueError("add_annotation requires valid numeric x/y ranges.")

    x_range = max(x_max - x_min, 1e-9)
    y_range = max(y_max - y_min, 1e-9)
    x_per_px = x_range / self.chart.width
    y_per_px = y_range / self.chart.height

    label_size = self.chart_style.get('annotation_label_size', self.chart_style.get('callout_label_size', 12))
    if label_size <= 6:
        label_size = self.em_to_px(label_size)
    # Derive line-height from effective font size + explicit inter-line padding.
    line_gap_px = self.chart_style.get('annotation_line_gap_px', max(1.5, label_size * 0.15))
    line_height_px = label_size + line_gap_px

    note_text = f"{title}\n{text}" if title else str(text)

    max_width_px = self.chart.width * self.chart_style.get(
        'annotation_max_width_ratio',
        self.chart_style.get('callout_max_width_ratio', 0.45)
    )
    approx_char_width = max(
        label_size * self.chart_style.get(
            'annotation_char_width_ratio',
            self.chart_style.get('callout_label_char_width_ratio', 0.5)
        ),
        self.chart_style.get(
            'annotation_min_char_width',
            self.chart_style.get('callout_label_min_char_width', 6)
        )
    )
    max_chars = max(int(max_width_px / max(approx_char_width, 1e-9)), self.chart_style['text_wrap_min_chars'])

    lines = text.split("\n")
    wrapped_text = []

    for line in lines:
        if not line.strip():
            wrapped_text.append("")
        else:
            wrapped_lines = textwrap.wrap(
                line,
                width = max_chars - 15, #piccola correzione
                break_long_words=False,
                break_on_hyphens=False,
                replace_whitespace=False,
            )

        wrapped_text.extend(wrapped_lines if wrapped_lines else [lines])


    max_line_chars = max(max(len(wrapped_line), 1) for wrapped_line in wrapped_text)
    box_width_px = min(max_line_chars * approx_char_width, max_width_px)
    box_height_px = max(len(wrapped_text), 1) * line_height_px
    box_padding_px = self.chart_style.get(
        'annotation_padding',
        self.chart_style.get('padding', 6)
    )
    text_left_padding_px = self.chart_style.get('annotation_text_left_padding_px', 2.0)
    text_top_padding_px = self.chart_style.get('annotation_text_top_padding_px', 2.0)

    box_w_data = (box_width_px + 5 * (box_padding_px + text_left_padding_px)) * x_per_px
    box_h_data = (box_height_px + (2 * box_padding_px)) * y_per_px
    text_padding_h = ((box_padding_px + text_top_padding_px) * y_per_px)

    # Box and text share the same top-left anchor by design.
    box_x_left = x + (dx * x_per_px)
    box_y_top = y - (dy * y_per_px)
    box_x_right = box_x_left + box_w_data
    box_y_bottom = box_y_top - box_h_data*line_gap_px
    text_x = box_x_left + ((box_padding_px + text_left_padding_px) * x_per_px)
    text_y = box_y_top - text_padding_h

    def connector_start_offset(dx_px, dy_px, w_px, h_px):
        if abs(dx_px) >= abs(dy_px):
            x_off = dx_px if dx_px > 0 else dx_px + w_px
            y_off = dy_px + (h_px / 2)
            return (x_off, y_off)
        if dy_px < 0:
            return (dx_px + (w_px / 2), dy_px + h_px)
        if dy_px > 0:
            return (dx_px + (w_px / 2), dy_px)
        return (dx_px + (w_px / 2), dy_px + (h_px / 2))

    conn_dx, conn_dy = connector_start_offset(dx, dy, box_width_px, box_height_px)
    connector_x = x + (conn_dx * x_per_px)
    connector_y = y - (conn_dy * y_per_px)

    tip_offset_ratio = self.chart_style.get(
        'annotation_tip_offset_ratio',
        self.chart_style.get('callout_peak_offset_ratio', 0.05)
    )
    vx = x - connector_x
    vy = y - connector_y
    tip_x = x - (vx * tip_offset_ratio)
    tip_y = y - (vy * tip_offset_ratio)

    annotation_data = pd.DataFrame({
        'subject_x': [x],
        'subject_y': [y],
        'connector_x': [connector_x],
        'connector_y': [connector_y],
        'tip_x': [tip_x],
        'tip_y': [tip_y],
        'box_x1': [box_x_left],
        'box_x2': [box_x_right],
        'box_y1': [box_y_bottom],
        'box_y2': [box_y_top],
        'text_x': [text_x],
        'text_y': [text_y],
    })

    text_color = text_color if text_color else self.colors.get('annotation_text', self.colors.get('callout_text', self.colors['context']))
    box_fill = background_color if background_color else self.colors.get('annotation_fill', self.context_box['fill'])
    box_stroke = self.colors.get('annotation_stroke', self.context_box['stroke'])
    line_color = line_point_color if line_point_color else text_color
    point_color = line_color
    point_size = self.chart_style.get('annotation_point_size', self.chart_style.get('callout_point_size', 60))
    line_width = self.chart_style.get('annotation_line_width', self.chart_style.get('callout_arrow_line_width', 2))
    box_opacity = self.chart_style.get('annotation_box_opacity', self.chart_style.get('callout_box_opacity', 1.0))
    box_border_width = self.chart_style.get('annotation_box_border_width', self.chart_style.get('callout_box_border_width', 1))

    layers = []
    if show_subject == True:
        dx = -50
        dy = -50
        layers.append(
            alt.Chart(annotation_data).mark_point(color=point_color, size=point_size).encode(
                x=alt.X('subject_x:Q'),
                y=alt.Y('subject_y:Q'),
            ).properties(width=self.chart.width, height=self.chart.height)
        )

        layers.append(
            alt.Chart(annotation_data).mark_rule(stroke=line_color, strokeWidth=line_width).encode(
                x=alt.X('connector_x:Q'),
                y=alt.Y('connector_y:Q'),
                x2='tip_x',
                y2='tip_y'
            ).properties(width=self.chart.width, height=self.chart.height)
        )

    if text is not None:
        layers.append(
            alt.Chart(annotation_data).mark_rect(
                color=box_fill,
                opacity=box_opacity,
                cornerRadius=self.context_box['corner_radius'],
                stroke=box_stroke,
                strokeWidth=box_border_width,
                dx = dx,
                dy = dy,

            ).encode(
                x=alt.X('box_x1:Q'),
                x2='box_x2',
                y=alt.Y('box_y1:Q'),
                y2='box_y2'
            ).properties(width=self.chart.width, height=self.chart.height)
        )


        # SEI QUI
        layers.append(
            alt.Chart(annotation_data).mark_text(
                text = wrapped_text,
                align='left',
                baseline='top',
                font=self.font,
                fontSize=label_size,
                lineHeight=line_height_px,
                lineBreak=self.chart_style['text_line_break'],
                color=text_color,
            ).encode(
                x=alt.X('text_x:Q'),
                y=alt.Y('text_y:Q')
            ).properties(width=self.chart.width, height=self.chart.height)
        )

    if img_url:
        y_img_offset = x_img_offset if x_img_offset != 0 else (-50 if text is not None else 0)
        y_img_offset = y_img_offset if y_img_offset != 0 else (50 if text is not None else 0)
        layers.append(
            alt.Chart(annotation_data)
                .mark_image(
                    width = img_width,
                    height = img_width,
                    baseline = "middle",
                    xOffset = x_img_offset,
                    yOffset = y_img_offset
                ).encode(
                    x=alt.X('text_x:Q'),
                    y=alt.Y('text_y:Q'),
                    url = alt.value(img_url)
                )
        )

    self.story_layers.append({'type': 'annotation', 'chart': alt.layer(*layers)})
    return self

add_line(value, orientation='horizontal', math=None, color='', label_text='', label_dx=0, label_dy=0, label_font_size='', label_font_weight='normal', label_font_style='normal')

Adds a reference line (horizontal or vertical) with an optional label to the story.

Parameters:

Name	Type	Description	Default
value	int | float | list | Series	Position of the reference line. If math is specified, must be a list or pandas.Series of numbers. Otherwise, must be a single numeric value (int or float).	required
orientation	str	Line orientation relative to axes. Must be either 'horizontal' or 'vertical'. Defaults to "horizontal".	'horizontal'
math	str	Automatic aggregation function to calculate value. Must be one of 'mean', 'median', 'min', or 'max'. Defaults to None.	None
color	str	Line and label text color. If omitted or None, falls back to the reference_line_color defined in the template layout settings. Defaults to None.	''
label_text	str	Custom text displayed alongside the line. If None, defaults to the formatted calculated value (e.g., "Mean 12.5" or "12.5"). Set to "" (empty string) to hide the label entirely. Defaults to None.	''
label_dx	int | float	Horizontal pixel offset for the label position. Defaults to 0.	0
label_dy	int | float	Vertical pixel offset for the label position. Defaults to 0.	0
label_font_size	int | float	Font size of the label text in pixels. If omitted or None, falls back to the line_label size defined in the template. Defaults to None.	''
label_font_weight	str	Font weight of the label text. Must be one of 'normal' or 'bold'. Defaults to "normal".	'normal'
label_font_style	str	Font style of the label text. Must be one of 'normal' or 'italic'. Defaults to "normal".	'normal'

Returns:

Name	Type	Description
Story		The current instance (self) to enable method chaining.

Raises:

Type	Description
TypeError	If value type does not match the requirements of math.
TypeError	If label_font_size is provided but is not an integer or float.
ValueError	If orientation is not 'horizontal' or 'vertical'.
ValueError	If math is not one of 'mean', 'median', 'min', 'max', or None.
ValueError	If label_font_weight is not 'normal' or 'bold'.
ValueError	If label_font_style is not 'normal' or 'italic'.

Source code in pynarrative/src/pynarrative/story.py

def add_line(
        self,
        value,
        orientation='horizontal',
        math = None,
        color = "",
        label_text = "",
        label_dx = 0,
        label_dy = 0,
        label_font_size = "",
        label_font_weight = "normal",
        label_font_style = "normal",
        ):
    """Adds a reference line (horizontal or vertical) with an optional label to the story.

    Args:
        value (int | float | list | pandas.Series): Position of the reference line.
            If `math` is specified, must be a list or `pandas.Series` of numbers.
            Otherwise, must be a single numeric value (`int` or `float`).
        orientation (str, optional): Line orientation relative to axes. Must be either
            `'horizontal'` or `'vertical'`. Defaults to "horizontal".
        math (str, optional): Automatic aggregation function to calculate `value`.
            Must be one of `'mean'`, `'median'`, `'min'`, or `'max'`. Defaults to None.
        color (str, optional): Line and label text color. If omitted or None, falls back to
            the `reference_line_color` defined in the template layout settings.
            Defaults to None.
        label_text (str, optional): Custom text displayed alongside the line. If None,
            defaults to the formatted calculated value (e.g., "Mean 12.5" or "12.5").
            Set to `""` (empty string) to hide the label entirely. Defaults to None.
        label_dx (int | float, optional): Horizontal pixel offset for the label position.
            Defaults to 0.
        label_dy (int | float, optional): Vertical pixel offset for the label position.
            Defaults to 0.
        label_font_size (int | float, optional): Font size of the label text in pixels.
            If omitted or None, falls back to the `line_label` size defined in the template.
            Defaults to None.
        label_font_weight (str, optional): Font weight of the label text.
            Must be one of `'normal'` or `'bold'`. Defaults to "normal".
        label_font_style (str, optional): Font style of the label text.
            Must be one of `'normal'` or `'italic'`. Defaults to "normal".

    Returns:
        Story: The current instance (`self`) to enable method chaining.

    Raises:
        TypeError: If `value` type does not match the requirements of `math`.
        TypeError: If `label_font_size` is provided but is not an integer or float.
        ValueError: If `orientation` is not `'horizontal'` or `'vertical'`.
        ValueError: If `math` is not one of `'mean'`, `'median'`, `'min'`, `'max'`, or None.
        ValueError: If `label_font_weight` is not `'normal'` or `'bold'`.
        ValueError: If `label_font_style` is not `'normal'` or `'italic'`.
    """

    if orientation not in ['horizontal', 'vertical']:
        raise ValueError(f"Invalid 'orientation' value: '{orientation}'. Must be either 'horizontal' or 'vertical'")
    if label_font_weight not in ["normal", "bold"]:
        raise ValueError("label_font_weight must be one of: 'normal', 'bold'")
    if label_font_style not in ["normal", "italic"]:
        raise ValueError("label_font_style must be one of: 'normal', 'italic'")

    def axis_type(axis):
        if hasattr(self.chart, 'encoding') and hasattr(self.chart.encoding, axis):
            shorthand = getattr(self.chart.encoding, axis).shorthand
            if shorthand and ':' in shorthand:
                return shorthand.split(':')[-1]
        return 'Q'


    #Math
    if math not in ["mean", "median", "min", "max", None]:
        raise ValueError(f"Invalid 'math' value: '{math}'. Must be one of: 'mean', 'median', 'min', 'max', or None")
    if math is not None:
        if not isinstance(value, (list, pd.Series)):
            raise ValueError("When 'math' is specified, 'value' must be a list or a pandas Series. Try something as: 'value = dataframe['value_column']' or 'value = dataframe['value_column'].tolist()")

        if len(value) == 0:
            raise ValueError("Cannot perform 'math' calculation on an empty sequence.")

        clean_values = [v for v in value if pd.notna(v)]

        if math == "mean": #Mean
            line_value = round(sum(clean_values) / len(clean_values), 2)
            print(f"Mean = {line_value}")

        elif math == "median": #Median
            line_value = round(float(np.median(clean_values)), 2)
            print(f"Median = {line_value}")

        elif math == "min": #Min
            line_value = round(float(min(clean_values)), 2)
            print(f"Min = {line_value}")

        elif math == "max": #Max
            line_value = round(float(max(clean_values)), 2)
            print(f"Max = {line_value}")
    else:
        if value is None or not isinstance(value, (int, float, np.number)):
            raise ValueError("When 'math' is None, 'value' must be a numeric integer or float.")
        line_value = float(value)
        print(f"Single value = {line_value}")


    # Crea un DataFrame con un singolo valore
    if orientation == 'horizontal':
        y_type = axis_type('y')
        data = pd.DataFrame({'y': [line_value]})
        encoding = {'y': f'y:{y_type}'}
    else:  # vertical
        x_type = axis_type('x')
        data = pd.DataFrame({'x': [line_value]})
        encoding = {'x': f'x:{x_type}'}


    # Crea la linea
    line_color = color if color else self.chart_style["reference_line_color"]

    line = alt.Chart(data).mark_rule(
        color = line_color,
        strokeWidth=self.chart_style['reference_line_width'],
        strokeDash=self.chart_style['reference_line_dash']
    ).encode(
        **encoding,
    )

    data_label = data.copy()
    if label_text is None:
        if math == "mean":
            label_text = f"Mean {str(line_value)}"
        elif math == "median":
            label_text = f"Median {str(line_value)}"
        else:
            label_text = str(line_value) #etichetta di default col valore numerico
    else:
        label_text = str(label_text)

    if orientation == 'horizontal':
        data_label['label_x'] = 0
        y_offset = self.chart_width + 10
        label_encoding = {**encoding, 'x': alt.value(y_offset)}
    else:  # vertical
        data_label['label_y'] = 0
        x_offset = -10
        label_encoding = {**encoding, 'y': alt.value(x_offset)}

    if label_font_size == "":
        font_size = self.em_to_px(self.font_sizes["line_label"])

    else:
        if not isinstance(label_font_size, (int, float)):
            raise TypeError("'label_font_size' must be an integer or float.")
        #else
        font_size = label_font_size

    label = alt.Chart(data_label).mark_text(
        color = line_color,
        fontSize = font_size,
        align = "left",
        dx = label_dx,
        dy = label_dy,
        fontWeight = label_font_weight,
        fontStyle = label_font_style,
    ).encode(
        **label_encoding,
        text = alt.value(label_text),
    )

    line = line + label

    # Aggiunge la linea ai layer della storia
    self.story_layers.append({
        'type': 'line',
        'chart': line
    })

    return self

render(save=False, filename=None, ppi=False)

Renders all elements, overlays, and structural layers of the story into a single compound chart.

Optionally exports the final visualization to a file in the export/ directory in SVG, PNG, or PDF format.

Parameters:

Name	Type	Description	Default
save	str | bool	Target output format for saving the chart. Must be one of 'svg', 'png', 'pdf', or False to skip saving. If an invalid string format is provided, a warning is raised and it falls back to 'svg'. Defaults to False.	False
filename	str | bool	Custom filename for export (without extension). If False or empty, falls back to the story's title text (formatted as snake_case) or 'no_name_chart' if no title exists. Defaults to None.	None
ppi	int | float	Pixels per inch resolution setting for PNG exports. Higher values increase render accuracy and image size. Defaults to 150.	False

Returns:

Type	Description
	alt.TopLevelSpec: The complete, stylized Altair chart specification.

Raises:

Type	Description
TypeError	If ppi is provided and is not a positive integer or float.
TypeError	If filename is provided (and not False) but is not a string.

Source code in pynarrative/src/pynarrative/story.py

def render(self, save = False, filename = None, ppi = False):
    """Renders all elements, overlays, and structural layers of the story into a single compound chart.

    Optionally exports the final visualization to a file in the `export/` directory in SVG,
    PNG, or PDF format.

    Args:
        save (str | bool, optional): Target output format for saving the chart.
            Must be one of `'svg'`, `'png'`, `'pdf'`, or `False` to skip saving.
            If an invalid string format is provided, a warning is raised and it falls
            back to `'svg'`. Defaults to False.
        filename (str | bool, optional): Custom filename for export (without extension).
            If `False` or empty, falls back to the story's title text (formatted as snake_case)
            or `'no_name_chart'` if no title exists. Defaults to None.
        ppi (int | float, optional): Pixels per inch resolution setting for PNG exports.
            Higher values increase render accuracy and image size. Defaults to 150.

    Returns:
        alt.TopLevelSpec: The complete, stylized Altair chart specification.

    Raises:
        TypeError: If `ppi` is provided and is not a positive integer or float.
        TypeError: If `filename` is provided (and not False) but is not a string.
    """

    if save not in ["svg", "png", "pdf", False]:
        warnings.warn(
            f"Unsupported export format '{save}'. Supported formats are 'svg', 'png', 'pdf'. "
            "Falling back to 'svg'.",
            UserWarning,
        )
        save = "svg"

    if filename is not None and not isinstance(filename, str):
        raise TypeError(f"'filename' must be a string or False, got {type(filename).__name__}")

    if save == "png":
        if ppi is False or ppi is None: ppi = 150
        if not isinstance(ppi, (int, float)) or ppi <= 0:
            raise TypeError("'ppi' must be a positive number.")
        if ppi > 500:
            warnings.warn(
                f"A high ppi value ({ppi}) was provided. This may significantly slow down chart rendering.",
                UserWarning,
            )

    def _vstack(charts, spacing = 1):
        if not charts:
            return None
        if len(charts) == 1:
            return charts[0]
        return alt.vconcat(*charts, spacing = spacing)

    # Let's start with the basic graph
    main_chart = self._apply_trendline_end_labels(self.chart)

    if hasattr(self, "label_layer"): #NUOVO (gestione labels)
        main_chart = alt.layer(main_chart, self.label_layer)

    # Create separate lists to place special graphics
    title_charts = []
    top_other_charts = []
    top_context_charts = []
    top_source_charts = []
    bottom_charts = []
    left_charts = []
    right_charts = []
    left_outer_charts = []
    right_outer_charts = []
    overlay_charts = []

    # Organise the layers according to their position
    for layer in self.story_layers:
        if layer['type'] == 'special_cta':
            # We take the position from the layer
            if layer.get('position') == 'top':
                top_other_charts.append(layer['chart'])
            elif layer.get('position') == 'bottom':
                bottom_charts.append(layer['chart'])
            elif layer.get('position') == 'left':
                left_charts.append(layer['chart'])
            elif layer.get('position') == 'right':
                right_charts.append(layer['chart'])
        elif layer['type'] == 'context' and layer.get('position') in ['left', 'right', 'top', 'bottom']:
            context_chart = self.create_context_box_chart(layer)
            if layer.get('position') == 'top':
                top_context_charts.append(context_chart)
            elif layer.get('position') == 'bottom':
                bottom_charts.append(context_chart)
            elif layer.get('position') == 'left':
                left_charts.append(context_chart)
            elif layer.get('position') == 'right':
                right_charts.append(context_chart)
        elif layer['type'] == 'title':
            title_charts.append(self.create_title_layer(layer))

        elif layer['type'] == 'source' and layer.get('position') in ['left', 'right']:
            source_side = self.create_source_side_chart(layer)
            if layer.get('position') == 'left':
                left_outer_charts.append(source_side)
            else:
                right_outer_charts.append(source_side)
        elif layer['type'] == 'source' and layer.get('position') in ["top", "bottom"]:
            overlay_charts.append(self.create_source_anchored_layer(layer)) #MODIFICATO


        elif layer['type'] in ['context', 'cta', 'source']:
            overlay_charts.append(self.create_text_layer(layer))
        elif layer['type'] in ['shape', 'shape_label', 'annotation']:
            overlay_charts.append(layer['chart'])
        elif layer['type'] == 'line':
            overlay_charts.append(layer['chart'])

    #Overlaying management in add_highlight() method
    if hasattr(self, '_overlays') and self._overlays:
        overlay_charts.extend(self._overlays)

    # Overlaying the layers on the main graph
    for overlay in overlay_charts:
        main_chart += overlay


    # Build the final layout
    left_stack = _vstack(left_charts)
    left_source_stack = _vstack(left_outer_charts)
    if left_source_stack is not None and left_stack is not None:
        # Keep left source before left context, but aligned on the same row as the chart.
        main_chart = alt.hconcat(left_source_stack, left_stack, main_chart)
    elif left_source_stack is not None:
        main_chart = alt.hconcat(left_source_stack, main_chart)
    elif left_stack is not None:
        main_chart = alt.hconcat(left_stack, main_chart)

    right_stack = _vstack(right_charts)
    right_source_stack = _vstack(right_outer_charts)
    if right_source_stack is not None and right_stack is not None:
        # Keep right source after right context.
        main_chart = alt.hconcat(main_chart, right_stack, right_source_stack)
    elif right_source_stack is not None:
        main_chart = alt.hconcat(main_chart, right_source_stack)
    elif right_stack is not None:
        main_chart = alt.hconcat(main_chart, right_stack)
    top_charts = top_context_charts + top_source_charts + top_other_charts
    if top_charts:
        main_chart = alt.vconcat(*top_charts, main_chart, center = True) #MODIFICATO
    if bottom_charts:
        main_chart = alt.vconcat(main_chart, alt.hconcat(*bottom_charts, center = True), center = True) #MODIFICATO
    if title_charts:
        main_chart = alt.vconcat(*title_charts, main_chart, center = True)

    # Apply configurations
    if 'view' in self.config:
        main_chart = main_chart.configure_view(**self.config['view'])

    #NUOVO
    mark_info = getattr(self.chart, "mark", None) #tipo di grafico
    mark_type = mark_info.type if hasattr(mark_info, "type") else mark_info
    if mark_type == "point":
        point_size = 150
        point_color = self.chart_style["series_colors"][0]
    elif mark_type == "line":
        point_size = 80
        point_color = self.chart_style["series_colors"][1]
    else:
        point_color = "#000000"
        point_size = 75

    # Apply default chart styling
    main_chart = main_chart.configure_view(
        strokeWidth=self.chart_style['default_view_stroke_width']
    ).configure_axis(
        grid=self.chart_style['axis_grid'],
        labelFont=self.chart_style['font'],
        labelColor=self.chart_style['label_color'],
        labelFontSize=self.chart_style['axis_label_size'],
        titleFont=self.chart_style['font'],
        titleColor=self.chart_style['title_color'],
        titleFontSize=self.chart_style['axis_title_size'],
        tickColor=self.chart_style['axis_tick_color'],
        domainColor=self.chart_style['axis_domain_color']
    ).configure_legend(
        labelFont=self.chart_style['font'],
        labelColor=self.chart_style['label_color'],
        labelFontSize=self.chart_style['legend_label_size'],
        titleFont=self.chart_style['font'],
        titleColor=self.chart_style['title_color'],
        titleFontSize=self.chart_style['legend_title_size']
    ).configure_title(
        font=self.chart_style['font'],
        color=self.chart_style['title_color'],
        fontSize=self.em_to_px(self.font_sizes['title'])
    ).configure_mark(
        strokeWidth=self.chart_style['line_stroke_width']
    ).configure_bar(
        color=self.chart_style['bar_fill_color']
    ).configure_line( #NUOVO: prende il primo colore della serie
        color=self.chart_style["series_colors"][0]
    ).configure_point(
        size = point_size,
        filled = True,
        color = point_color
    ).configure_range(
        category = self.chart_style["series_colors"]
    )

    if self._is_bar_chart():
        wrap_threshold = self.chart_style['bar_label_wrap_threshold']
        main_chart = main_chart.configure_axisX(
            labelAngle=0,
            labelLineHeight=self.chart_style['bar_label_line_height'],
            labelExpr=(
                f"length(datum.label) > {wrap_threshold} "
                "? replace(datum.label, /\\s+/, '\\n') : datum.label"
            )
        )

    #SAVE
    if not filename: #default
        filename = "no_name_chart"
        for layer in self.story_layers:
            if layer["type"] == "title":
                filename = layer["title"]
        filename = filename.lower()
        filename = re.sub(" ", "_", filename)

    if save is not False:
        os.makedirs("export", exist_ok = True) #crea la cartella export se non esiste
        export_path = f"export/{filename}.{save}"

        if save == "png":
            try:
                main_chart.save(export_path, ppi = ppi)
            except TypeError:
                main_chart.save(export_path)
        else:
            main_chart.save(export_path)

        print(f"Your file '{filename}.{save}' was successfully exported to the 'export/' directory.")

    return main_chart.resolve_axis(x="shared", y="shared")
